AlphaNANO 1.75 Filter
AlphaNANO 2.5 Filter
AlphaNANO 4.25 Filter
AlphaNANO 6.0 Filter
AlphaNANO 10.0 Filter
AlphaNANO 10.3 Filter
AlphaNANO 6.3 Filter 3
AlphaNANO Megladon 23.3 Filter
AlphaNANO Megladon 33.3 Filter
AlphaNANO X2 10.0 Filter
AlphaNANO X2 6.0 Filter
The AlphaNANO series of filters are also available as complete pond filtration systems that are preplumbed with the AlphaNANO filter, Pump and UV all on Black equipment pads ready to set up and go when you get them. For more info on our complete systems click here
The AlphaNANO Filter was developed over 2 years ago. We sought out help from some of our qualified and knowledgeable Contractors, dealers and pond owners, to help us with our testing and give us feed back. In two years of testing we received "0" negative comments. This surpassed even our greatest expectations. Some of these were new pond owners and many were previous owners of different types of bead filters. The AlphaNANO media has about 50% more surface area for Beneficial Bacteria to grow than a Bead Filter has for surface area.
| Model | Size (cu. ft.) | Max Pond Size | Flow Rate (gpm) | Fish Load (lbs.) | Dimensions |
|---|---|---|---|---|---|
|
AlphaNANO1.75 |
1.75 2.5 |
2500 gallons(U.S.) 5,000 gallons (U.S.) |
50 gpm 70 gpm |
90 lbs. 125 lbs. |
19" x 31" 21" x 32" |
|
AlphaNANO4.25 |
4.25 | 10,000 gallons (U.S.) | 90 gpm | 225 lbs. | 24.75" x 34" |
| AlphaNANO 6.0 | 6.0 | 17,000 gallons (U.S.) | 120 gpm | 300 lbs. | 30.5" x 36.75" |
| AlphaNANO 10.0 | 10.0 | 25,000 gallons (U.S.) | 180 gpm | 500 lbs. | 36 7/8" x 42" |
To answer this we have to understand the difference between bead filters and how they trap solids and how the AlphaNANO Filter accomplishes this task. Bead filters trap solids in the first few inches of the bead pac(causing clogging, flow disruption and pressure rises in the vessel) while the AlphaNANO with its uniquely designed AlphaNANO media stops the debris evenly through out the pac (resulting in greater flow, less head or back pressure, less maintenance.) The polishing ability of the filter is one it's most desirable features, based upon comments that have come into us from the field.
The AlphaNANO media was specially designed for this filter. It is not something borrowed from another industry or use. Its design is unique in that it was not designed with "cross hairs" as some other specialty types of media use. We left those out because in a static bed the "cross hairs" can collect and hold debris until it becomes anaerobic. With the AlphaNANO media there are no hidden areas for anaerobic bacteria, to harbor and stagnate, only beneficial bacteria.
FAQS
Q1: How is the AlphaNANO filter different from traditional bead filters?
A1: Unlike bead filters, which trap solids in the first few inches of the media, the AlphaNANO filter distributes debris evenly throughout the media pack. This results in better flow, less back pressure, and reduced maintenance needs.
Q2: What makes the AlphaNANO media so unique?
A2: The AlphaNANO media was specifically designed for this filter. It doesn’t use “cross hairs” like other types of specialty media, which can trap debris and cause anaerobic conditions. The AlphaNANO media only supports beneficial bacteria growth, promoting a healthier pond environment.
Q3: How does the AlphaNANO filter improve water clarity?
A3: The AlphaNANO filter’s superior polishing ability effectively removes fine debris from the water, leading to clearer water and improved overall pond health.
Q4: Is the AlphaNANO filter easy to integrate into my existing pond system?
A4: Yes! The AlphaNANO filter is designed to be compatible with a variety of pond setups. It is also available as part of a complete system, including the filter, pump, and UV unit, all pre-plumbed for easy installation.
